Vandal-Resistant, Wall-Mounted, Square Drinking Fountain - Non-Refrigerated, ADA, Stainless Steel
Downloads
Resource Type | Title | Description | File Size | Action | |
|---|---|---|---|---|---|
 | | Murdock Mfg - Drinking Fountains | 164 KB | ||
 | | Rounded Box, Barrier-Free, Wall Mount Drinking Fountain with Vandal Resistant Button | 156 KB | ||
| | Rounded Box, Barrier-Free, Wall Mount Drinking Fountain with Vandal Resistant Button - right side looking at the unit | 323 KB | ||
| | 143 KB | |||
 | | Rounded Box Barrier-Free Wall Mount Drinking Fountain [Standard Model A151400S, A151400S-SO (Sensor)] | 1004 KB | ||
| | Rounded Box, Barrier-Free, Wall Mount Drinking Fountain with Vandal Resistant Button [Standard Model A151400S-VR] | 177 KB | ||
| | Murdock Care and Cleaning Guide - for Stainless Steel and Enviro-Glaze® Powder Coated Products | 95 KB | ||
| | Murdock Mfg - Drinking Fountains | 169 KB | ||
| | Indoor Water Coolers, Bottle Fillers and Drinking Fountains Brochure (pdf) | 3 MB | ||
 | | Murdock® water fountains, bottle fillers, and hand washing stations are made from high-quality, durable stainless steel, one of the easiest materials to clean and disinfect. | 134 KB |
Specifications
| Style | Indoor Rounded Box |
| Product Features | Auto-Stop (Servicing Strainer Shuts Off Water Supply), Round Vandal-Resistant Pushbutton |
| Material | Stainless Steel |
| Material Detail | Bronze, High-Polish Gold, High-Polish Stainless Steel, All-Stainless Steel |
| Mounting | Wall-Mounted |
| Activation | Push Button |
| Compliances | IAPMO tested to NSF/ANSI 61, Section 9 |
| Patent | US 10,100,933 B2 (Auto-Stop Feature) |
Options
Accessories
Image | Model | Description | Downloads | |
|---|---|---|---|---|
 | -AD1 | Accessory: Wall Mount Access Door | ||
 | -AP1 | Accessory: Wall Mounted Single Access Panel | ||
 | -BP2 | Accessory: Stainless Steel Back Panel for A15 Series Drinking Fountain | ||
 | -CSC | Accessory: Concealed Support Carrier, Wall Mounted Drinking Fountain or Hand Wash | ||
 | -MF1 | Accessory: Mounted Frame for Single Non-Refrigerated Drinking Fountain | ||
 | A9100080-A | Accessory: 8 GPH Remote Chiller for Refrigerated Drinking Fountains | ||
 | WF3000 | Accessory: 3,000 Gallon PFAS Water Filter |
Miscellaneous
Image | Model | Description | Downloads | |
|---|---|---|---|---|
 | -SO | Option: Sensor Activation with Plug-in Transformer | ||
 | FRA1 | Option: Above Ground, Freeze-Resistant Valve, Single Station Fountain |
Models
Typical models are shown below
A151400S-VR All-Stainless Steel Lead-Free Stainless Steel Bubbler
A151400F-VR All-Stainless Steel, Flexible Bubbler
A151400S-VR-HP High Polished Stainless Steel, Lead-Free Stainless Steel Bubbler
A151200S-VR Bronze Finish with matching finish bubbler
A151300S-VR High Polished Gold Finish with matching finish bubbler
Popular Options/Accessories include:
-AP1 | Access panel for single fountain -AD1 | 10" x 10" access door -BP2 | Back panel for single fountain - CSC | Concealed support carrier -MF1 | Mounting frame for a single fountain -FRA1 | Freeze-resistant valve -SO | Sensor Operated Valve
Note: Mounting plate A0000000-MP1 may be ordered in advance for a pre-mounted rough-in.
Details
This fountain features a round vandal-resistant push button with an auto-stop.
The patented Push Button Auto Stop feature is part of Murdock's A15-VR units. It seamlessly incorporates the heavy-duty Vandal Resistant button for additional security while allowing easy access to the push button for routine maintenance.
How does Murdock do this? An integral fine screen strainer, an extra feature, captures any small debris in the supply line, preventing it from entering the push-button cartridge. When the strainer is removed, the water flow to the cartridge is stopped, allowing easy front access for its removal and replacement. Once the retaining ring is snugged down after cartridge replacement and the strainer is returned to its position, the stream height exiting the bubbler is easily adjusted right from the front of the button. Remember, this is ALL done without the time-consuming disassembly of the unit for routine maintenance!
